Cisco 8832 IP Conference Phone (CP-8832-K9=)

Cisco 8832 IP Conference Phone (CP-8832-K9=)

The Cisco IP Conference Phone 8832 provides a simple, flexible, scalable solution that meets the challenges of the most diverse rooms. With the base unit alone, it provides 360-degree coverage for any 20x20-foot room and up to 10 participants. With the optional wired extension microphone kit, it covers any 20x34-foot room and up to 22 participants. With the optional wireless extension microphone kit, it covers any 20x40-foot room and up to 26 participants. With a daisy-chain configuration of two 8832 units along with the optional wireless extension microphone kit, it covers up to a 20x57-foot room and up to 42 participants. It is ideal for executive offices, conference rooms, and boardrooms.

Note: CP-8832-K9= is the base unit only and does not include any Ethernet or power adapters. May come in NR (Non-Radio) or standard configuration.

Features

• 3.9-inch 480x128-pixel color LCD
• Textile cover for soft touch and durability
• Large mute button in the middle of the device for easy access from all angles
• LED indicator above the mute button showing the call status
• Raised edge for easier handling and repositioning on tabletop
• Crisp, precise button tactility
• Single USB-C port on the device to minimize the number of cables on the table (an Ethernet injector is required for any non-Wi-Fi deployment)
• 360-degree room coverage; base unit alone covers up to a 10-foot microphone pickup range
• Compatible with both IEEE 802.3af and 802.3at Power over Ethernet (PoE) Class 3 consumption (both PoE and non-PoE Ethernet injector options are available, sold separately)
• Includes Atlas 1-Year Warranty with Extended Warranty options available!

Specifications

• Power over Ethernet (PoE) deployment option: Either a Cisco IP Conference Phone 8832 PoE Injector or a Cisco IP Conference Phone 8832 Ethernet Injector is required.
• Non-PoE Ethernet deployment option: A Cisco IP Conference Phone 8832 non-PoE Ethernet Injector is required.
• Wi-Fi deployment option: A Cisco IP Conference Phone 8832 Power Adapter is required.
• Daisy-chain deployment: Two 8832 based units and a daisy-chain kit (CP-8832-DC=) required.
